DIN 1.2083 steel is chromium alloyed stainless plastic mold steel. It is equivalent to AISI 420 steel. The steel 1.2083 is a major steels for hot pressing in circulation.
1.2083 stainless steel is generally supplied annealed condition with a hardness < 230HB. It can also be delivered ESR and quenched and tempered to 320 HB.
Main characteristics of DIN 1.2083 are :
– a good atmospheric corrosion resistance,
– an excellent polishability,
– a good machinability in annealed condition,
– a high hardenability
– a good wear resistance


Chemical Composition
DIN ISO 4957 | C | Mn | P | S | Si | Cr | ||
1.2083 / X40Cr14 | 0.36 | 0.42 | max 1.0 | 0.03 | 0.03 | max 1.0 | 12.50 | 14.50 |
Relevant Specifications and Equivalents
ISO EN 4957 | ASTM A681 |
1.2083 / X40Cr14 | 420 |
